LIM Glass S4 - aluminum frosted front door with four transparent stripe

SKU
LIM Glass S4
Rating:
100 % of 100
1  Review Add Your Review
AVAILABLE
$5,470.00

The price includes TAX & shipping

Click here to select the configuration

Doors are manufactured after the order has been placed through the website.
Production time for our doors:
door named LIM (aluminum) - production takes 6 weeks
door named STA (stainless steel) - production takes 4 weeks
door named FARGO (stainless steel) - production takes 7 weeks

Size door with frame:
Width from: 35.4" to 51"
Height from: 78.7" to 96"

Available door colors:
 anthracite, white, black, silver gray, red, blue, yellow, brown, green, walnut, wenge, golden oak, mahogany, custom from RAL palette

Our exterior doors with hinges on the side are hurricane impact rated. (for more details please contact us)

Specification

The multi-point lock FUHR is used for locking. It has many locking and control configurations.
Glazing in the door leaf: triple glazing glass
Thickness of polyurethane foam in the leaf: 1.9"
Thermal insulation: R-Value 5.9

The door set includes:

- Aluminum door and the door frame;
- door handle made of stainless steel;
- 3-part roller hinges in the same color as the door;
- Multipoint locking system 855GL : full locking in 7 points, - 2 hooks, - 4 bolts plus upper bolt
- Threshold strip 0.6" height;
- anti-burglary class lock insert with 5 keys.

Full door information

The door is already mounted onto the frame (prehung door), which saves you all the work. The door is completely ready for installation.

The picture showing how to take the measurement. Click here
The installation space between the frame and the wall can be between 0.2" to 0.8" on each side.
Frequently Asked Questions: click here to check

-
+
$5,470.00

The price includes TAX & shipping

Wish List
Email
We found other products you might like!

Profile construction

Specification

  • frame depth: 70 mm / 2.76 inch ,
  • Thermal insulation: Ud = 1.0 W/(m2*K) / R-Value 5.6
  • The multi-point lock FUHR is used for locking
  • Thickness of polyurethane foam in the leaf: 48 mm / 1.9"

The door set includes:

  • Aluminum door and the door frame;
  • door handles made of stainless steel;
  • roller hinges in the same color as the door
  • Multipoint locking system 855GL : full locking in 7 points, - 2 hooks, - 4 bolts plus upper bolt
  • Threshold strip 15 mm / 0.59" height;
  • anti-burglary class lock insert with 5 keys.

Glazing

The glass in our doors are triple-pane windows. All panes are connected with spacer frames. Two of them are covered with Low-E coatings that provide natural light while helping to limit heat gain and thermal energy loss. It is also possible to choose P4 anti-burglary glass or safety glass VSG 33.1

standard glazing package 4th/16Ar/4/16Ar/4th

safety glass 33.1//4//4

P4 anti-burglary

Types of glazing

There is a wide range of glass options. In our offer one will find energy-saving, sound-absorbing, safety, anti-burglary and sunscreen windows. The most popular ones are milk glass, decorative or mirror glass as well as bronze reflex glass.

Colours

Colours can emphasise the shape of aluminium joinery and provide it with individual character and genuine appearance. All aluminium systems offered are available in two colour palettes – RAL and DECORAL.
RAL Basic colour palette.

Fiery red or maybe a delicate blue? The RAL K5 Classic colour palette will allow you to choose the colour of the door perfectly suited to your requirements!



RAL 1003

RAL 2004

RAL 3020

RAL 5002

RAL 6005

RAL 6021

RAL 7016

RAL 7039

RAL 7040

RAL 9016

RAL 9005

RAL 9007

DECORAL woodgrain finish palette

Aluminium doors can also have more traditional, woodlike finishes such as: beech, sweet cherry, golden oak, winchester, mahogany, walnut, dark oak, pine, cherry, wenge.



Golden Oak

Mahogany

Walnut

Wenge

Beech

Roller hinges WR WALA

WR WALA are minimalistic, modern looking, high quality roller hinges. They have been tested and are certified by the German IFT ROSENHEIM. Hinges are protected by patent law and can be adjusted: vertically: -5 to 5mm / -0.2" to 0.2", gap: -2.5 to 2.5 mm / -0.1" to 0.1" , seal pressure: -1.5 to 1.5 mm / -0.05" to 0.05" . When it comes to finish they are available in stainless steel or any colour from the RAL palette (hinges will be painted in the same colour as the door). Depending on the door height there are at least 3 hinges per door leaf/slab.

greenteQ handles

QreenteQ handles are made of anodized aluminum with high resistance to corrosion, weather conditions and scratches.
The INOX version is made of matt stainless steel.
Handle with fixed/rotary bearing and return spring mechanism adapted to the pin square 8 mm / 0.3".
TThe escutcheon/cover plate is 35 mm / 0.14" wide.

T-bar - long vertical handle or normal handle:

Stainless steel door handles are designed for one or two-sided use for external doors.
The innovative mounting system enables quick and easy installation of the door handle. Our offer includes many handrails:




Q45
T-bar at an angle of 45 degrees with a square section of 40 × 40 mm / 1.6"x1.6"
Available in lengths: 1200 / 47.2", 1500 / 59", 1800 mm / 70.9".

P45
T-bar at an angle of 45 degrees with a round cross-section ⌀ 40 mm / 1.6".
Available in lengths: 1200 / 47.2", 1500 / 59", 1800 mm / 70.9".

Z32
Black T-bar with an interesting curve that can also be used for all-glass doors
Available in length 499 mm / 19.6".

Multi-point lock Hook-bolts 855GL type-11

  • steel hooks and pins
  • Three-dimensional locking with integrated hooks and metal pins for optimal security.
  • Pressure adjustment.

Class A insert 6.D.C cylinder with keys

Durability: 100 000 cycles
Security rating: Class 6 the highest
Attack resistance: Class D the highest
Burglar resistance: Class C the highest

Certified, cylindrical, profiled 9-ratchet insert (two rows of latches).
Innovative anti-drill and anti-picking protection.
Inserts resistant to bumping. 5 keys included, key code card.

Write Your Own Review
You're reviewing:LIM Glass S4 - aluminum frosted front door with four transparent stripe
Your Rating

The LIM Glass S4 frosted front door with four transparent stripes is a sophisticated and contemporary entry solution that perfectly balances privacy, natural light, and modern design aesthetics. Designed for homeowners and businesses seeking a stylish yet functional entrance, this door elevates the look and feel of any property with its sleek lines and thoughtfully crafted details. It stands as a testament to innovative craftsmanship, combining durability and elegance to create a truly distinctive focal point for any facade.

At the heart of the LIM Glass S4 is its beautifully frosted glass surface, which offers a smooth, matte finish that ensures privacy without completely blocking light. This frosted effect softens the view through the door, allowing natural daylight to gently diffuse into the interior space, creating an inviting and warm atmosphere. The frosting is precisely applied to maintain a uniform appearance that complements a wide range of architectural styles—from minimalist and modern homes to more traditional or transitional designs.

The defining feature of the LIM Glass S4 is the inclusion of four transparent horizontal stripes that run across the door’s frosted surface. These clear bands provide a dynamic visual contrast that adds depth and sophistication to the overall design. Beyond their aesthetic appeal, the transparent stripes allow carefully calibrated glimpses of the outside world, enhancing the connection between indoor and outdoor environments while maintaining a high level of privacy. This design element also maximizes the entry of natural light, brightening the foyer or entrance hall and contributing to an open, airy feel without compromising security or seclusion.

Construction quality is paramount in the LIM Glass S4. The door is crafted using high-grade tempered or laminated glass, known for its strength, durability, and resistance to impact. This ensures the door can withstand daily use, weather conditions, and security demands without sacrificing its pristine appearance. The supporting frame and hardware are made from premium materials designed to provide smooth operation, secure locking mechanisms, and long-lasting reliability. These features collectively offer peace of mind alongside the door’s striking aesthetic appeal.

The versatility of the LIM Glass S4 frosted front door makes it an excellent choice for a variety of settings. Its neutral frosted glass combined with the subtle transparency of the stripes allows it to seamlessly integrate with diverse exterior designs and color palettes. Whether installed in contemporary urban residences, stylish offices, or upscale commercial properties, the LIM Glass S4 adapts effortlessly to enhance any entrance. Furthermore, its low-maintenance glass surface ensures the door remains easy to clean and retains its elegant look through years of use.

In conclusion, the LIM Glass S4 frosted front door with four transparent stripes is an exceptional blend of style, privacy, and functionality. It offers a modern and inviting entrance that enriches both the curb appeal and interior ambiance of any property. For those who desire a door that makes a bold yet refined statement, while delivering durability and ease of maintenance, the LIM Glass S4 is the perfect choice—combining innovative design with lasting quality to welcome guests with elegance and light.
