LIM MN1 - fully glazed aluminum entry door with muntins (glazing bars)

SKU
LIM MN1
AVAILABLE
$5,607.00

The price includes TAX & shipping

Click here to select the configuration

Doors are manufactured after the order has been placed through the website.
Production time for our doors:
door named LIM (aluminum) - production takes 6 weeks
door named STA (stainless steel) - production takes 4 weeks
door named FARGO (stainless steel) - production takes 7 weeks

Size door with frame:
Width from: 35.4" to 61"
Height from: 78.7" to 112.6"

Available door colors:
anthracite, white, black, silver gray, red, blue, yellow, brown, green, walnut, wenge, golden oak, mahogany, custom from RAL palette

Our exterior doors with hinges on the side are hurricane impact rated. (for more details please contact us)

You can order this door model in a smaller size. View Pivot C9

Specification

The multi-point lock FUHR is used for locking. It has many locking and control configurations.
Hinges: the choice of wing or roller hinges and concealed hinges.
Glazing in the door leaf: triple glazing glass
Thickness of polyurethane foam in the leaf: 2.7"
Thermal insulation: R-Value 8.3
Sound insulation: 30dB

The door set includes:

- Aluminum door and the door frame;
- door handle made of stainless steel;
- 3-part roller hinges in the same color as the door;
- Multipoint locking system 855GL : full locking in 7 points, - 2 hooks, - 4 bolts plus upper bolt
- Threshold strip 0.6" height;
- anti-burglary class lock insert with 5 keys.

Full door information

The door is already mounted onto the frame (prehung door), which saves you all the work. The door is completely ready for installation.

The picture showing how to take the measurement. Click here
The installation space between the frame and the wall can be between 0.2" to 0.8" on each side.

Frequently Asked Questions: click here to check

-
+
$5,607.00

The price includes TAX & shipping

We found other products you might like!

Profile construction

Specification

  • frame depth: 70 mm / 2.76 inch ,
  • Thermal insulation: Ud = 1.0 W/(m2*K) / R-Value 5.6
  • The multi-point lock FUHR is used for locking
  • Thickness of polyurethane foam in the leaf: 48 mm / 1.9"

The door set includes:

  • Aluminum door and the door frame;
  • door handles made of stainless steel;
  • roller hinges in the same color as the door
  • Multipoint locking system 855GL : full locking in 7 points, - 2 hooks, - 4 bolts plus upper bolt
  • Threshold strip 15 mm / 0.59" height;
  • anti-burglary class lock insert with 5 keys.

Glazing

The glass in our doors are triple-pane windows. All panes are connected with spacer frames. Two of them are covered with Low-E coatings that provide natural light while helping to limit heat gain and thermal energy loss. It is also possible to choose P4 anti-burglary glass or safety glass VSG 33.1

standard glazing package 4th/16Ar/4/16Ar/4th

safety glass 33.1//4//4

P4 anti-burglary

Types of glazing

There is a wide range of glass options. In our offer one will find energy-saving, sound-absorbing, safety, anti-burglary and sunscreen windows. The most popular ones are milk glass, decorative or mirror glass as well as bronze reflex glass.

Colours

Colours can emphasise the shape of aluminium joinery and provide it with individual character and genuine appearance. All aluminium systems offered are available in two colour palettes – RAL and DECORAL.
RAL Basic colour palette.

Fiery red or maybe a delicate blue? The RAL K5 Classic colour palette will allow you to choose the colour of the door perfectly suited to your requirements!



RAL 1003

RAL 2004

RAL 3020

RAL 5002

RAL 6005

RAL 6021

RAL 7016

RAL 7039

RAL 7040

RAL 9016

RAL 9005

RAL 9007

DECORAL woodgrain finish palette

Aluminium doors can also have more traditional, woodlike finishes such as: beech, sweet cherry, golden oak, winchester, mahogany, walnut, dark oak, pine, cherry, wenge.



Golden Oak

Mahogany

Walnut

Wenge

Beech

Roller hinges WR WALA

WR WALA are minimalistic, modern looking, high quality roller hinges. They have been tested and are certified by the German IFT ROSENHEIM. Hinges are protected by patent law and can be adjusted: vertically: -5 to 5mm / -0.2" to 0.2", gap: -2.5 to 2.5 mm / -0.1" to 0.1" , seal pressure: -1.5 to 1.5 mm / -0.05" to 0.05" . When it comes to finish they are available in stainless steel or any colour from the RAL palette (hinges will be painted in the same colour as the door). Depending on the door height there are at least 3 hinges per door leaf/slab.

greenteQ handles

QreenteQ handles are made of anodized aluminum with high resistance to corrosion, weather conditions and scratches.
The INOX version is made of matt stainless steel.
Handle with fixed/rotary bearing and return spring mechanism adapted to the pin square 8 mm / 0.3".
TThe escutcheon/cover plate is 35 mm / 0.14" wide.

T-bar - long vertical handle or normal handle:

Stainless steel door handles are designed for one or two-sided use for external doors.
The innovative mounting system enables quick and easy installation of the door handle. Our offer includes many handrails:




Q45
T-bar at an angle of 45 degrees with a square section of 40 × 40 mm / 1.6"x1.6"
Available in lengths: 1200 / 47.2", 1500 / 59", 1800 mm / 70.9".

P45
T-bar at an angle of 45 degrees with a round cross-section ⌀ 40 mm / 1.6".
Available in lengths: 1200 / 47.2", 1500 / 59", 1800 mm / 70.9".

Z32
Black T-bar with an interesting curve that can also be used for all-glass doors
Available in length 499 mm / 19.6".

Multi-point lock Hook-bolts 855GL type-11

  • steel hooks and pins
  • Three-dimensional locking with integrated hooks and metal pins for optimal security.
  • Pressure adjustment.

Class A insert 6.D.C cylinder with keys

Durability: 100 000 cycles
Security rating: Class 6 the highest
Attack resistance: Class D the highest
Burglar resistance: Class C the highest

Certified, cylindrical, profiled 9-ratchet insert (two rows of latches).
Innovative anti-drill and anti-picking protection.
Inserts resistant to bumping. 5 keys included, key code card.

Write Your Own Review
You're reviewing:LIM MN1 - fully glazed aluminum entry door with muntins (glazing bars)
Your Rating

The LIM MN1 is a fully glazed aluminum entry door with elegant muntins (glazing bars), designed for those who want their entrance to feel bright, modern, and architecturally refined. It brings together the transparency of a glass door, the strength and precision of aluminum, and the timeless character of a divided-light design. The result is a statement entry door that enhances the exterior of your home or building while flooding the interior with natural light.

At first glance, the LIM MN1 immediately stands out for its clean, contemporary lines and full-height glazing. The expansive glass panel creates a sense of openness and connection between indoors and outdoors, making your hallway, foyer, or entrance area feel larger, lighter, and more welcoming. This is an ideal solution for homeowners and designers who value minimalism and clarity, but still want a door with real visual interest and structure.

The defining feature of the LIM MN1 is its muntins, also known as glazing bars. These slim horizontal and vertical profiles divide the large glass area into smaller panes, forming a stylish grid pattern that recalls classic steel doors, industrial loft windows, and elegant heritage façades. The glazing bars give the door rhythm and proportion, turning a simple sheet of glass into a sophisticated design element. They also make it easy to coordinate the door with other architectural details, such as grid-style windows, internal glass partitions, or steel-look room dividers.

Crafted from high-quality aluminum, the LIM MN1 is engineered for durability and long-term stability. Aluminum does not warp, swell, or crack as temperatures and humidity levels change, making it far more reliable over time than many traditional materials. This structural integrity allows for slim frames and muntins that support large glass surfaces while maintaining narrow, refined sightlines. You get a sleek, lightweight look without sacrificing robustness or security.

The aluminum profiles and glazing bars are finished using advanced powder-coating technology, creating a hard-wearing, UV-resistant surface that maintains its colour and appearance for years. Whether you prefer classic matte black for a steel-look effect, deep anthracite grey for a sophisticated modern touch, or other neutral or bolder architectural colours, the LIM MN1 can be tailored to suit your exterior and window frames. The frame and muntins are perfectly colour-matched, ensuring a cohesive, high-end aesthetic from every angle.

Although the LIM MN1 is visually light and transparent, it is designed to perform as a secure, dependable entry door. The robust aluminum frame can be combined with high-quality multi-point locking systems, secure cylinders, and reinforced keeps to protect against forced entry. The glass itself can be specified as toughened or laminated safety glazing, significantly increasing impact resistance and enhancing security. This means you can enjoy the benefits of a fully glazed entrance without compromising on peace of mind.

Thermal comfort is another key consideration. Modern aluminum systems used in the LIM MN1 can incorporate thermal breaks that separate the inner and outer sections of the frame, reducing heat transfer. When paired with high-performance double or triple glazing, the door helps maintain a more stable indoor temperature, supporting energy efficiency in both cold and warm seasons. Effective seals and gaskets around the perimeter further improve airtightness, helping keep out draughts, moisture, and dust.

The glass options for the LIM MN1 allow you to fine-tune both appearance and performance. Clear glass maximises light and views, making it ideal if you want a strong visual connection to your garden, driveway, or outdoor spaces. Frosted, satin, or patterned glass provides privacy while still allowing abundant natural light to enter, which is perfect for more exposed entrances or urban locations. In addition, specialist coatings can be applied to improve solar control, reduce glare, or enhance thermal insulation.

Acoustic comfort can also be improved through the right glazing choice. In homes situated on busier roads or in lively neighbourhoods, the use of laminated or acoustic glass helps reduce outside noise transmission, creating a quieter, more relaxing entrance area. Combined with the solid, high-quality frame construction, the LIM MN1 offers a balanced mix of openness and acoustic protection.

One of the major advantages of the LIM MN1 is its low maintenance. Unlike timber doors, aluminum does not need regular sanding, painting, or varnishing. A simple clean with mild soapy water is usually sufficient to keep the frame and muntins looking fresh, while the glass can be cleaned like any standard window. The powder-coated surface is designed to resist peeling, flaking, and fading, even under heavy use and varying weather conditions, making this door an excellent choice for busy households and long-term projects.

Design flexibility is integral to the LIM MN1 concept. The layout of the glazing bars can often be selected or configured to suit your aesthetic preferences, whether you prefer a subtle, fine grid or a bolder, more graphic pattern with fewer, larger panes. The door can be manufactured in various sizes, from standard dimensions to taller or wider designs that create a more dramatic entrance. Hardware options such as modern pull handles, classic lever handles, and minimalist handle sets are available in multiple finishes, including stainless steel, black, and colour-matched variants, enabling you to complete the look in a way that reflects your style.

The LIM MN1 is well suited to a wide variety of architectural contexts. In modern homes, it creates a sleek, gallery-like entrance that pairs beautifully with large windows, flat roofs, and minimalist detailing. In renovated period properties, it brings a fresh, contemporary twist while echoing traditional divided-light patterns often found in original windows and doors. In commercial environments such as offices, studios, boutiques, and showrooms, it projects an image of quality, transparency, and design awareness from the very first impression.

Overall, the LIM MN1 fully glazed aluminum entry door with muntins (glazing bars) is the perfect choice if you are looking for a door that combines generous natural light, distinctive grid styling, and reliable everyday performance. It offers the visual lightness of glass, the strength and precision of aluminum, and the classic appeal of divided panes, all in one carefully engineered product. With its blend of aesthetics, security, insulation, and low maintenance, the LIM MN1 is designed to enhance your entrance for many years to come.
